Cable Drive

Converting continuous rotation to oscillatory motion.
Using twincam and two levers reduces the spring deformation. See “Cable drive 12a” of this channel for comparison.
Beside creating friction between the yellow wheel and the cable, the spring ensures a permanent contact between rollers and cam and compensates velocity difference of the cable ends caused by the two levers.
