Cam and Gear Mechanism

The yellow follower contacts with the orange cam fixed on the orange gear. The cam is of constant width shape. The pink plate has a slot in which an eccentric pin of the green gear slides. A point of the frame follower traces the red curve that is used for moving film in cameras. Transmission ratio of the gear drive is 2.
