Cam of Two Followers

Input: pink cam causing two motions of blue and yellow followers.
The blue follower oscillates with dwell at its leftest position.
The yellow follower has planar motion. Green closed curve is locus of a point on it.
Spring maintains the cam contact with the yellow follower.
