Checking Parallelism Between Two Planes

One plane is large enough for laying the indicator base.
Move the indicator set longitudinally to get values E1 and E2 at two points, distance between which is A.
Non-parallelism P = (E1-E2)/A
Using height gauge gives less accurate result.
