Epicyclic Bar Angular Transmission

Input: green arm and blue shaft
Output: pink shaft.
The video shows alternately:
1. The green arm is kept immobile, the blue shaft rotates.
2. The green arm rotates, the blue shaft is kept immobile.
3. Both green arm and blue shaft rotate in different directions.
