External-Internal Gear Drive of Adjustable Shaft Angle

Green gear is of regular spur one.
Teeth of pink gear is combination of spur and face ones.
It is an attempt to increase adjustable range of the shaft angle to 180 deg.
There are considerable backlashes between teeth of the two gears.
