Friction Roller Drive

Input: the green roller.
Output: the pink shaft of 3 cranks carrying 3 blue idle rollers.
The orange flexible rings contacts with the green input roller and the fixed outer ring. Initial deformation of the orange flexible rings creates contact pressure which can be regulated to some extent by the cyan bolt.
