Friction Sphere Variator

Input: the blue shaft having two orange disks of spherical cap.
The yellow and red disks have sliding key joints with the green output shaft.
A spring creates contact pressure between the disks.
Turn the pink screw for moving the input shaft to get desired output velocity.
