Gear and Linkage Mechanism

Three gears have a same tooth number.
The yellow glass gear is immobile.
Crank radii of two orange gears are equal to gear pitch ones.
Input : green carrier rotating regularly.
Output: blue shaft rotating irregularly with dwell.
The pink and green curves are loci of red rollers centers.
