Gear and Linkage Mechanism

Pink and orange gears (tooth numbers: 16 and 24) have revolution joints with the blue rocker. The orange gear has revolution joint with green rocker. The two rocker and the orange gear create a 4-bar linkage. When the pink input gear rotates regularly, two rockers (green and blue) oscillate. Their motion depends on the 4-bar linkage dimension.
