Gear, Rack and Linkage Mechanism

Violet carrier, yellow satellite gears, blue and green gears create a differential planetary mechanism.
The blue gear is connected to the violet carrier via pink gear, orange rack and a sine mechanism.
The pink input gear rotates regularly.
The output green gear rotates irregularly.
Its motion is a sum of regular rotation and irregular rotation of sine function.
