Geneva Mechanism

Input: pink crank
Output: green disk rotating with dwells.
In one revolution of the pink crank the green disk rotates 180 deg., a thing that ordinary Geneva mechanisms can not get.
Orange sliders prevent reverse rotation of the green disk when yellow roller of the pink crank reaches corners of the disk grooves.
