Geneva Mechanism

Angle between the two pins is 120 degrees.
During 1 revolution of the driving shaft the driven disk has 2 dwell times and 2 motion times alternately. Dwell periods of the two dwell times are different.
Angle of each rotation of the driven shaft is 120 degrees.
