Internal and External Gears

The left planetary drive can be replaced by the right one when the manufacturing of internal gears is a problem. They give the same result (the green curves). Just lengthen the carrier and add an yellow double gear.
In this video tooth number of the fixed gears is triple of the one of the movables gears so the green curves are deltoids.
