Internal Gear Slider Mechanism

The yellow gear (Z2 = 20 teeth) is fixed to the connecting rod.
The green gear (Z1 = 80 teeth) is not fixed to the pink input crank.
The green output gear irregularly continuously rotates slower than the pink crank in the opposite direction.
