Liquid Dispenser

Pink continuously rotating cam moves green cylinder to pump out a determined liquid amount during each revolution.
Ball valves are operated automatically thanks to fluid pressure and their own weights. Orange screw is for adjusting liquid amount to be pumped.
Red arrow shows time when the liquid flows out.
