Loci in Epicyclic Gearing

R: pitch diameter of the fixed sun gear
r: pitch diameter of the planetary gear
k = R/r = 4
A point on pitch circle of the planetary gear traces a special hypocycloid: astroid (green)
The blue slotted crank has 4 dwells in a revolution.
