Machine Tool Fixture

Clamping a workpiece (in yellow) by hydraulic cylinder through a blue wedge and orange levers.
Spherical portions on the pink part and the blue wedge are needed to compensate dimension error of the workpiece.
The workpiece and the greey positioning disk are cut off half for easy understanding.
