Mechanism Creating Two Parallel Runways

OB/OA = BP/AQ = OD/OC = DP/CQ
When pink crank rotates, two orange swivel runways are always parallel to each other.
This mechanism was numbered as 1314 in Artobolevski book, Mechanisms in modern technic, Moscow 1977, vol 2.
