Mechanism for Converting Two-Way to One-Way Rotation

The orange input gear may change rotation direction but the rotation direction of the blue and green gears keeps unchanged.
The yellow idle gear moves in the curved slot because of gear forces.
There is a slight lag during the input gear’s reverse.
The mechanism should be used only for low speed case because of gear collision.
