Pair of Compasses

Pink nuts have revolution joints with the legs. The screw has planar joint with the handle.
Turn screw of two opposite handed threads to alter distance between needle points. The legs are coaxial and turn in opposite directions with the same velocity to ensure that the handle is always on the bisector of the angle created by the legs.
