Blue, orange, green and yellow bars create a pantograph.
Two red pins and blue one are in line.
The blue pin traces a circle. Its center O lays on O1O2:
OO2 = O1O2(FE/AF)
Its radius R depends on angular position between pink and violet cranks and their radii.
