Pick and Place Mechanism

Green piston of violet cylinder makes pink pin of blue bar move along a slot on yellow plate. At the same time, orange pin of the blue bar moves along a slot on grey plate.
The mechanism can be used for the following scenario:
The blue bar moves down to pick a workpiece, moves up, turns left, moves to the left, releases the workpiece there and returns to initial position.
