Pick and Place Mechanism

Input: pink crank rotating continuously.
Yellow ball bearing on green pin moves along oblique slot of white base.
Orange square slider fixed to green pin moves along L-shaped slot of white base.
The vacuum tool at the green bar end picks and places workpieces.
This is a combination of a slider-crank mechanism and a wedge one.
