Pin Gear Drive 26 May 2017, 19:00 Sorry, your browser doesn't support embedded videos, but don't worry, you can download it and watch it with your favorite video player! Input: the cyan shaft having an arm. Output: the pink pin wheel. In 1 revolution of the cyan shaft, the arm makes the output rotate 1/8 rev. The green rim keeps the output immobile during its pause period. « previous mechanism Transmission of Linear Displacement next mechanism » Machine Tool Fixture load comments Please enable JavaScript to view the comments.
