Blue and pink links create a parallelogram mechanism.
Orange cylinder turns the grey pipe 90 deg.
Violet cylinder translates the pipe.
Violet cylinder is of a double acting telescopic cylinder to increase motion range.
Pipe clamping device is not shown.
