Press of Double Toggle Action

Input: pink crank.
When the crank and blue bar are vertical, they together with green and yellow bars create a parallelogram.
The double toggle action (when the pink crank, the blue bar are in line and green bar, yellow bar are in line) gives a strong working force.
