Press of Two Coaxial Sliders

Input: pink eccentric shaft.
Upper and lower sliders move oppositely thanks to two slider crank mechanisms of grey common crank on each side.
This mechanism can be used for compressing grain materials from both sides.
In one side compression materials near immobile side are not compressed as tightly as the ones near mobile side.
