Pump With Eccentric

Input: orange rotor that rotates eccentrically in the housing.
Two blue levers with green cushions are forced toward the rotor by pink springs.
It is an application of a 4-bar linkage where green cushions are the connecting rods.
The arrows show fluid flows.
The pump is cut off half for easy understanding.
