Pump With Eccentric

Input: grey rotor that rotates eccentrically in the housing.
Green conrod separates suction and discharge spaces of the pump.
The rotor, conrod and pink slider create a slider crank mechanism.
The arrows show fluid flows.
The pump is cut off half for easy understanding.
