Push-Turn Button Mechanism

Press yellow button to reach forward position of the blue pin.
Orange leaf spring enters into a hole on the grey base to prevent the blue button go back under action of pink spring.
Turn yellow button to return the blue pin to its initial position.
Eccentric pin of the yellow button pulls the orange spring out of the hole on the grey base.
