Rack Pinion Mechanism 08 December 2016, 13:00 Sorry, your browser doesn't support embedded videos, but don't worry, you can download it and watch it with your favorite video player! Yellow double rack receives motion from motor via pink worm. The left rack engages with the pink worm and the blue gear. The yellow double rack makes two face gears rotate in opposite directions. Gears and racks are made of sheet metal. « previous mechanism Application of Parallelogram Mechanism next mechanism » Conchoids of a Straight Line load comments Please enable JavaScript to view the comments.
