Railway Hand Car

Swing green double lever to move the car via a 4 bar linkage and a gear drive.
Reverse of swinging means reversing the car.
Step on the red knob to operate a crank slider mechanism for braking.
This video is made based on G.S. Sheffield’s invention in 1882.
