Ratchet Mechanism

Input: green crank oscillating.
Output: blue ratchet wheel.
Both go and back motions of ocsillating green crank make the wheel rotate in the same direction.
Yellow pawl pushes and orange pawl pulls the wheel.
Gravity maintains contact between pawls and wheel.
