Robot Head of Rotation DoF

Black head fixed to grey angular part has two degrees of freedom:
- Rotation around vertical axis.
- Rotation around horizontal axis.
Each motion is controlled by a grounded step motor.
It’s a spherical mechanism (axes of all five revolution joints are concurrent).
Video scenario: Observation.
