Roller Overrunning Clutch

Green outter disk and blue inner disk rotate around a fixed axis.
The arrows show which link is the driving at different times.
When the outter disk is driving, its two way rotation can be transmitted to the inner disk only in clockwise direction.
When the inner disk is driving, its two way rotation can be transmitted to the outter disk only in anticlockwise direction.
