Sarrus Linkage

Sarrus linkage 1
A space linkage of only revolution joints and gives absolutely straight motion. It was invented in 1853, sooner than the planar Peaucellier linkage (1864).
It is the combination of two planar slider-crank mechanisms that lay in two perpendicular to each other planes.
