Input: pink crank.
Output: green slider that linearly reciprocates with dwell at both ends of stroke.
Yellow slider moves along the dovetail shaped groove of the green slider.
Violet screws are for adjusting positions of orange sliders to get various stroke lengths of the green slider.
Ball spring devices for positionning the green slider at its end positions are not shown.
