Slider-Crank Mechanism With Gears on Conrod

The orange gear and orange crank are fixed together.
The blue and pink gears, each rotates idly on its axle.
The orange and pink gear have the same tooth number.
The input crank rotates regularly while the blue and pink gears rotates irregularly.
