Snap Motion

A latch mounted on a cocking lever (blue) allows both levers to be reached at the same time with one hand.
Rotate the latch clockwise to release the cocking lever.
Rotate the cocking lever anticlockwise to get the initial position.
A coil spring always forces the pink latch to rotate anticlockwise.
