Spatial Friction Drive for Translating Motion

Input: orange shaft rotating regularly.
Output: yellow slider linearly reciprocating.
The slider velocity depends on the skew angle between axes of the input shaft and the roller.
Pink roller is forced toward the input shaft by a spring (not shown).
