Spherical R Mechanism for Speed Reduction

The input and output shafts are parallel.
Transmission ratio is 4. The pink output link revolves nearly regularly. Velocity error is +/- 2.5% of average velocity.
The mechanism has been created only on computer, needs to be verified in practice.
