Straight Line Drawing Mechanism

It is an isosceles slider-crank mechanism.
Every point of the small circle (fixed with the violet conrod and its radius r is equal to the conrod length) traces a straight line.
The small circle rolls inside the large fixed circle of 2r radius. They are Cardano circles.
