Study of Spatial Parallelogram Mechanism

Lower and upper plates are identical.
Green vertical bars are identical.
All joints are spherical.
Distance between two joints of the plates and of yellow horizontal bar are equal.
In general lower and upper plates are kept parallel but there is the case shown in this video.
