Toggle Linkage

Pink crank rotates at constant velocity while orange crank moves slowly at the beginning and end of the stroke. It moves rapidly at the midstroke when the orange crank and the green conrod are in toggle. The accelerated weight on the orange crank absorbs energy and returns it to the system when it slows down.
This mechanism is used as an impact reducer in some large circuit breaker.
