Transmission With Teeth-Uncompleted Gears

Input: the green gear of 1 tooth of special profile.
Output: the pink gear
The teeth are of special profiles.
When the green makes 1 revolution, the pink turns 1/6 rev.
The arcs on both gears keep the output gear immobile during its pause period.
