Transmission With Teeth-Uncompleted Gears

Planetary drive with dwell.
R1: pitch diameter of the green gear having 20 teeth.
R2: pitch diameter of the yellow gear having 20 teeth.
R3: pitch diameter of the orange gear having 1 tooth.
R4: pitch diameter of the blue internal gear having 12 tooth slots.
R1 = R2 = R3; R4 = 3R1
The green gear is input.
The output pink crank carrying the yellow and orange gear block rotates with periodical pauses.
