Red lever position determines right or left hand thread to be turned. It changes rotation direction of the yellow lead screw in relation with the rotation direction of the blue chuck.
Gears represent the gear train that determines the lead of the thread to be created.Device (electrical or mechanical) for reversing rotation direction of the chuck is not shown.
