Two Directional Clamping

Turn green nut to clamp or release yellow workpiece.
Red springs tends to release the workpiece.
Contact surface between the nut and violet jaw is spherical.
The screw-nut drive is set floating. The violet and pink jaws may not move synchonically but at the end they clamp tightly the workpiece.
