Wire-Cutting Mechanism

Input: green and blue shafts rotating at the same velocity and in opposite directions.
Pink cutters cut yellow wire that moves continuously. Velocities of the wire and the cutters at cutting point are about equal.
The mechanism is used for cutting steel of reinforced concrete.
